| Type | HDL Anglock Vise | Weight | 98 lbs |
| Jaw Width | 3 1/4″ | Overall Length | 21 1/4″ |
| Jaw Opening Capacity | 4″ | Overall Height | 3 1/8″ |
| Jaw Height | 1.485″ | Set Includes | 6″ Base Vise With Hard Jaw Kit |
| Model No | HDLM6J | Overall Width | 3 1/4″ |
| Jaw Depth | 1.728″ |
Product Features
| Remarks | •High density long vises with two clamping stations. They provide repeatable clamping to .002″ and combine high density with heavy duty features. Designed on rugged 80,000 PSI ductile iron body with steel components, provide strength, rigidity and long term accuracy while absorbing machining vibration. •Full 4″ opening in each station with standard jaw system •Maximizes number of parts in the work envelope •Adjustable pre-load feature allows you to minimize pre-load range thus reducing the turns of the handle to open of close the vise. •Holding block features the ability to clamp same or dissimilar sized parts and provides pre-loading ability in the front or back jaw. •Hydraulic models also available ? please inquire | Country of Origin | USA |
Shipping Info
Hazard Code
W
Shipping Notes
Weighted Item. Additional Costs Apply.
Package Length
27.50000
Package Width
9.00000
Package Height
6.00000
Package Weight
101.2
