| Thread Diameter Size (TDZ) | 1″ | Applicable Material | | Steel | Cast Iron | Aluminum / Non-Ferrous Materials | |
| Threads per Inch (TPI) | 11.5 | Chamfer | 2.5P |
| Thread Standard | NPT | Coating | Black Oxide |
| Usable Length (LU) | 1.751″ | Cutting Edge Material | HSS |
| Flute Count (NOF) | 5 | Measurement Type | Inch |
| Overall Length (OAL) | 3-3/4″ | Series/List # | 108 |
| Thread Cutting Part Length (THL) | 1-3/4″ | Thread Size | 1″ - 11.5 |
| Connection Diameter Machine Side (DCONMS) | 1-1/8″ |
Product Features
| Remarks | •Regular thread
•OSG List #108. | Country of Origin | Mexico |
Shipping Info
Package Length
3.90000
Package Width
1.60000
Package Height
1.60000
Package Weight
0.908
