| Thread Diameter Size (TDZ) | 1-1/4″ | Coolant Supply Property (CSP) | External |
| Threads per Inch (TPI) | 11.5 | Cutting Direction (HAND) | Right Hand |
| Thread Standard | NPT | Coating | Uncoated |
| Flute Helix Angle (FHA) | CW|25 Degrees | Cutting Edge Material | HSS |
| Flute Count (NOF) | 5 | Measurement Type | Inch |
| Overall Length (OAL) | 6-19/64″ | Flute Length | 2-5/64″ |
| Thread Cutting Part Length (THL) | 1-7/32″ | Standard | PWZ-NORM |
| Connection Diameter Machine Side (DCONMS) | 1.26″ | Thread Size | 1-1/4″ - 11.5 |
| Flute Type | Straight |
Product Features
| Family Description | 25167-NPT1.1/4 | Country of Origin | Germany |
Shipping Info
Package Weight
2.078
