5/8-18 2B SP PT STI BOTT TAP-HARDSL

| Tool Type | STI Tap | Coating | HL |
| Style | Straight | Coolant Supply Property (CSP) | External |
| Thread Diameter Size (TDZ) | 5/8″ | Flute Helix Angle (FHA) | 40 Degrees |
| Thread Tolerance Class (TCTR) | 2B | Shank Type | Square |
| Thread Standard | UNF | Flute Type | Spiral Point |
| Thread Cutting Part Length (THL) | 1.111″ | Usable Length (LU) | 1.81″ |
| Threads per Inch (TPI) | 32 | Measurement Type | Inch |
| Overall Length (OAL) | 4.03″ | Connection Diameter Machine Side (DCONMS) | 0.542″ |
| Cutting Edge Material | HSSE | Standard | 322 |
| End Shape | Bottoming | Length Group | 3xD |
| Flute Count (NOF) | 3 | Series/List # | ST |
| Chamfer | 1.5P-2P | Thread Size | 5/8″ - 32 |
Product Features
| Country of Origin | S.Korea |
Shipping Info
Package Length
4.25
Package Width
0.875
Package Height
0.875
Package Weight
0
