MTI 10086 D25 2 TR MT8
Thread Mill; Tr12 2|Tr14 2 × 2 mm ; 10 mm Shank Dia. × 2.9″ OAL ; Carbide ; TiAlN ; MT8 ; Series MTI
| Thread Size | Tr12 × 2|Tr14 × 2 | Coating | TiAlN |
| Thread Pitch (TP) | 2 mm | Application | MINI MILL THREAD |
| Thread Standard | TRAPEZ (DIN 103) | Applicable Material | | General Purpose | |
| Connection Diameter Machine Side (DCONMS) | 10 mm | Cutting Edge Material | Carbide |
| Cutting Diameter (DC) | 8.6 mm | Cutting Position | Internal |
| Functional Length (LF) | 24.9 mm | Series/List # | MTI |
| Overall Length (OAL) | 2.9″ | Measurement Type | Metric |
| Flute Count (NOF) | 4 | Grade | MT8 |
| Coolant Supply Property (CSP) | External | Cutting Direction (HAND) | | Left Hand | Right Hand | |
Product Features
| Country of Origin | Israel |
Shipping Info
Package Weight
.1570
