MTZ 12113 D26 18UN
Thread Mill; 1(1/8) - 1(5/8)|9/16 - 5/8 - 18 ; 12 mm Shank Dia. × 3.3″ OAL ; Carbide ; TiAlN ; MT7 ; Series MTZ
| Thread Size | 1(1/8) - 1(5/8)|9/16 - 5/8 | Coating | TiAlN |
| Threads per Inch (TPI) | 18 | Application | MILL THREAD SOLID CARBIDE |
| Thread Standard | UN | Applicable Material | | General Purpose | |
| Connection Diameter Machine Side (DCONMS) | 12 mm | Cutting Edge Material | Carbide |
| Cutting Diameter (DC) | 11.3 mm | Cutting Position | Internal |
| Functional Length (LF) | 26.1 mm | Series/List # | MTZ |
| Overall Length (OAL) | 3.3″ | Measurement Type | Metric |
| Flute Count (NOF) | 4 | Grade | MT7 |
| Coolant Supply Property (CSP) | Coolant Thru | Cutting Direction (HAND) | | Left Hand | Right Hand | |
Product Features
| Country of Origin | Israel |
Shipping Info
Package Weight
0.258
