FLD 3040L AC50E API
| Threads per Inch (TPI) | 5 | Thread Pitch Maximum (TPX) | 0.344 mm |
| Application | | Int Ext Threading Flo Lock | | Insert to Shank Reference | 0.082″ |
| Insert Thickness (S) | 0.195″ | Cutting Edge Length (L) | 0.399″ |
| Corner Radius (RE) | 0.0175″ | Coating | TiAlN |
| Body Material | Carbide | Measurement Type | Inch |
| Grade | AC50E | Thread Form Type (THFT) | API Partial Profile |
| Cutting Direction (HAND) | Left Hand |
Product Features
| Family Description | Internal and External API Rotary Shoulder Non-Topping Profile FloLock Threading Inserts w/Left Hand Clamping Notch | Country of Origin | USA |
Shipping Info
Package Weight
0.22
