MPHX080305-A57 Grade WKP25S
Milling Insert; 8.3 mm Length × 8.3 mm Width × 3.18 mm Thickness ; WKP25S ; Carbide ; | TiCN | Al2O3 |
Additional Tariff Surcharge of 8 %
| Applicable Material | | Steel | Cast Iron | | Shape | 86° Diamond |
| Cutting Edge Length (L) | 8.3 mm | Insert Style | MPHX |
| Corner Radius (RE) | 0.5 mm | Insert Size | 80305 |
| Depth of Cut Maximum (APMX) | 0.327″ | Cutting Direction (HAND) | Neutral |
| Insert Width (W1) | 8.3 mm | Chip Breaker Type | A57 |
| Inscribed Circle Diameter (IC) | 8.3 mm | Series/List # | MPHX-WKP25S |
| Insert Thickness (S) | 3.18 mm | Hole Diameter | 3.4 mm |
| Insert Included Angle (EPSR) | 86 Degrees | Cutting Edge Material | Carbide |
| Coating | | TiCN | Al2O3 | | Tool Type | Single sided Inserts |
| Grade | WKP25S | Number of Cutting Edges | 2 |
Product Features
| Family Description | MPHX080305-A57 WKP25S | Country of Origin | Germany |
Shipping Info
Package Weight
0.079
