RDGT 0803M0ERGM PR1535 Grade PVD Carbide, Indexable Milling Insert
Milling Insert; RDGT0803M0ERGMPR1535 PVD PR1535 × 0.315″ Width × 1/8″ Thickness ; Carbide ; MEGACOAT NANO
| Applicable Material | | Steel | Stainless Steel | Super-Alloys / Titanium | | Insert Size | 803 |
| Application | Facing | Pocketing | Profiling | Ramping | Shouldering | Slotting | Clearance Angle Major (AN) | 15 Degrees |
| Insert Width (W1) | 0.315″ | Cutting Direction (HAND) | Right Hand |
| Inscribed Circle Diameter (IC) | 0.315″ | Chip Breaker Type | M0ER-GM |
| Insert Thickness (S) | 1/8″ | Series/List # | MRX |
| Coating | MEGACOAT NANO | Hole Diameter | 0.1181″ |
| Grade | PR1535 | Cutting Edge Material | Carbide |
| Shape | Round | Coating Process | PVD |
| Insert Style | RDGT | Measurement Type | Inch |
Product Features
| Country of Origin | Japan |
Shipping Info
Package Weight
.140
