LNCX 1806AZ-R11 GP5D
Milling Insert; LNCX 1806AZ-R11 GP5 GP5D ; TiN
| Applicable Material | | Steel | Stainless Steel | | Shape | 90?? Rectangular |
| Application | | Ext Milling | | Maximum Feed per Tooth (fz(max)) | 0.25 mm/tooth |
| Insert Length (INSL) | 0.739″ | Corner Chamfer Width (CHW) | 0.085″ |
| Corner Radius (RE) | 0.025″ | Cutting Edge Material | Carbide |
| Insert Width (W1) | 0.394″ | Tool Type | Single sided Inserts |
| Insert Thickness (S) | 1/4″ | Minimum Feed per Tooth (fz(min)) | 0.15 mm/tooth |
| Insert Included Angle (EPSR) | 44 Degrees | Measurement Type | Inch |
| Coating | TiN | Body Material | Carbide |
| Grade | GP5D |
Product Features
| Family Description | Rectaingle Face Milling Inserts | Country of Origin | USA |
Shipping Info
Package Weight
0.44
