M12x1.75 3FL 6H High Speed Steel Spiral Point Tap - Steam Oxide
Spiral Point Tap; M12 × 1.75 mm ; 3-3/8″ OAL ; 3 FL ; HSS ; Black Oxide ; 6H ; Series 288
| Thread Standard | Metric | Cutting Edge Material | HSS |
| Thread Size | M12 × 1.75 | Tool Type | Hand Tap |
| Thread Diameter Size (TDZ) | M12 | Applicable Material | | Steel | Aluminum / Non-Ferrous Materials | |
| Thread Pitch (TP) | 1.75 mm | Connection Diameter Machine Side (DCONMS) | 9.32 mm |
| Thread Tolerance Class (TCTR) | 6H | Thread Cutting Part Length (THL) | 1-21/32″ |
| Usable Length (LU) | 35 mm | End Shape | Spiral Point |
| Overall Length (OAL) | 3-3/8″ | Style | Plug |
| Chamfer | 4P-4.5P | Measurement Type | Metric |
| Coating | Black Oxide | Series/List # | 288 |
| Flute Count (NOF) | 3 |
Product Features
| Country of Origin | Mexico |
Shipping Info
Package Length
5.00000
Package Width
.75000
Package Height
.70000
Package Weight
0.115
