M8x1.25 SC Straight Flute Semi-Bottoming Coolant Tap E-code # T200M8
Straight Flute Tap; M8 × 1.25 mm ; 90 mm OAL ; 3 FL ; Carbide ; TiCN ; Series T200
Additional Tariff Surcharge of 8 %
| Thread Diameter Size (TDZ) | M8 | Coating | TiCN |
| Thread Pitch (TP) | 1.25 mm | Tapping Prehole Diameter (Pre-hole) | 6.9 mm |
| Thread Standard | M | Flute Length | 22 mm |
| Overall Length (OAL) | 90 mm | Flute Type | Straight |
| Thread Cutting Part Length (THL) | 22 mm | Style | Semi-Bottoming |
| Usable Length (LU) | 35 mm | Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 8 mm | Coolant Supply Property (CSP) | External |
| Flute Count (NOF) | 3 | Measurement Type | Metric |
| Cutting Edge Material | Carbide | Series/List # | T200 |
| Tool Type | Machine Tap | Thread Size | M8 × 1.25 |
Product Features
| Family Description | E-code # T200M8 | Country of Origin | Germany |
Shipping Info
Package Weight
0.19
