VTSFT6035 3/4-10 UNC 2B 4F DIN376 C
Spiral Flute Tap; 3/4″ - 10 ; 5.51″ OAL ; 4 FL ; HSSCo ; Oxide ; 2B
Additional Tariff Surcharge of 8.5 %
| Thread Diameter Size (TDZ) | 3/4″ | Thread Tolerance Class (TCTR) | 2B |
| Threads per Inch (TPI) | 10 | Standard | DIN376 |
| Thread Standard | UNC | Chamfer | 2P-3P |
| Overall Length (OAL) | 5.51″ | Coating | Oxide |
| Thread Cutting Part Length (THL) | 1.18″ | Flute Type | Spiral |
| Connection Diameter Machine Side (DCONMS) | 0.63″ | Style | Semi-Bottoming |
| Flute Count (NOF) | 4 | Cutting Direction (HAND) | Right Hand |
| Flute Helix Angle (FHA) | 45 Degrees | Coolant Supply Property (CSP) | External |
| Applicable Material | | Steel | Stainless Steel | | Square Size | 0.472″ |
| Cutting Edge Material | HSSE | Measurement Type | Inch |
Product Features
| Country of Origin | Germany |
Shipping Info
Package Weight
.0265
