3/4″ Dia. × 3/4″ Shank × 1-5/8″ DOC × 4″ OAL, Carbide FC20, 9 Flute, Variable Helix, Round, External , Ballnose End Mill
BN End Mill; 3/4″ Dia. × 1-5/8″ LOC × 3/4″ Shank Dia. × 4″ OAL ; 9 FL ; Carbide ; Series 3600
| Cutting Diameter (DC) | 3/4″ | Corner Radius (RE) | 0.09″ |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Tool Type | Single-End |
| Depth of Cut Maximum (APMX) | 1-5/8″ | End Shape | Corner Radius |
| Overall Length (OAL) | 4″ | Coolant Supply Property (CSP) | External |
| Cutting Edge Material | Carbide | Decimal Equivalent | 0.75″ |
| Flute Count (NOF) | 9 | Measurement Type | Inch |
| Flute Helix Angle (FHA) | Variable | Series/List # | 3600 |
| Shank Type | Round |
Product Features
| Remarks | •Cutter diameter tolerance: +.0/-.002•Shank diameter tolerance: h6•Material used in: steels, stainless, high temp alloys, and Titanium•Center cutting | Country of Origin | USA |
Shipping Info
Package Weight
0.74
