3/4″ Dia. × 3/4″ Shank × 2-1/4″ DOC × 5″ OAL, Carbide FC20, 9 Flute, Variable Helix, Round, External , Ballnose End Mill
BN End Mill; 3/4″ Dia. × 2-1/4″ LOC × 3/4″ Shank Dia. × 5″ OAL ; 9 FL ; Carbide ; Series 3600
| Cutting Diameter (DC) | 3/4″ | Shank Type | Round |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Tool Type | Single-End |
| Depth of Cut Maximum (APMX) | 2-1/4″ | End Shape | Square |
| Overall Length (OAL) | 5″ | Coolant Supply Property (CSP) | External |
| Cutting Edge Material | Carbide | Decimal Equivalent | 0.75″ |
| Flute Count (NOF) | 9 | Measurement Type | Inch |
| Flute Helix Angle (FHA) | Variable | Series/List # | 3600 |
Product Features
| Remarks | •Cutter diameter tolerance: +.0/-.002•Shank diameter tolerance: h6•Material used in: steels, stainless, high temp alloys, and Titanium•Center cutting | Country of Origin | USA |
Shipping Info
Package Length
6.50000
Package Width
1.25000
Package Height
1.25000
Package Weight
1.07
