‎KEO 931 Solid Carbide G-Mill DIA-3/32 × 3/4 11x Reach Length 3 Flute 8xD Flute Length Ballnose Amorphous Diamond Coated

‎BN End Mill; 3/32″ Dia. × 1/8″ Shank Dia. × 2-1/2″ OAL ; 3 FL ; Carbide ; DLC

Item # 1139202

Brand: ARCH Cutting Tools

MFG #: ‎931-000-507

Legacy Part #: RM10AD30938XRB

Trade Name: KEO

Quantity Available

Cutting Diameter (DC)

3/32″

Usable Length (LU)

3/4″

Connection Diameter Machine Side (DCONMS)

1/8″

Corner Radius (RE)

0.046″

Overall Length (OAL)

‎2-1/2″

Tool Type

Single-End

Cutting Edge Material

Carbide

Length Group

Extra Reach

Coating

DLC

End Shape

Ball Nose

Flute Count (NOF)

Decimal Equivalent

0.09375″

Product Features

Remarks

•35° Helix •Diameter tolerance: +.000″/-.001″(except as noted) •AD (Amorphous Diamond) coated "G" Mills are specifically designed for machining graphite electrodes. •"G" Mills have been shown to be a cost effective solutions in producing graphite electrodes by lowering tooling costs and improving productivity. •Designed with a Fast Helix and 3- or 4- flute design, "G" Mills outperform conventional end mills by providing faster particle evacuation while producing extremely smooth finishes in graphite. •"G" Mills are factory laser inspected to ensure more accurate machining of graphite electrodes.

Country of Origin

USA

Shipping Info

Package Length

3.16000

Package Width

.12000

Package Height

.12000

Package Weight

0.01
