KEO 931 Solid Carbide G-Mill DIA-5/64 × 5/64 3 Flute Long Flute Ballnose Amorphous Diamond Coated
BN End Mill; 5/64″ Dia. × 1/8″ Shank Dia. × 2-1/2″ OAL ; 3 FL ; Carbide ; DLC
| Cutting Diameter (DC) | 5/64″ | Usable Length (LU) | 1/2″ |
| Connection Diameter Machine Side (DCONMS) | 1/8″ | Corner Radius (RE) | 0.039″ |
| Overall Length (OAL) | 2-1/2″ | Tool Type | Single-End |
| Cutting Edge Material | Carbide | Length Group | Long Flute|Long Shank |
| Coating | DLC | End Shape | Ball Nose |
| Flute Count (NOF) | 3 | Decimal Equivalent | 0.078125″ |
Product Features
| Remarks | •35° Helix •Diameter tolerance: +.000″/-.001″(except as noted) •AD (Amorphous Diamond) coated "G" Mills are specifically designed for machining graphite electrodes. •"G" Mills have been shown to be a cost effective solutions in producing graphite electrodes by lowering tooling costs and improving productivity. •Designed with a Fast Helix and 3- or 4- flute design, "G" Mills outperform conventional end mills by providing faster particle evacuation while producing extremely smooth finishes in graphite. •"G" Mills are factory laser inspected to ensure more accurate machining of graphite electrodes. | Country of Origin | USA |
Shipping Info
Package Weight
0.01
