MS60-11T304M-L50 1040
Additional Tariff Surcharge of 8 %
| Applicable Material | | Steel | Stainless Steel |Super Alloys / Titanium | | Insert Size | 11T3 |
| Application | Shoulder Milling | Clearance Angle Major (AN) | 6.5 Degrees |
| Cutting Edge Length (L) | 5 mm | Cutting Direction (HAND) | Right |
| Corner Radius (RE) | 0.4 mm | Chip Breaker Type | L50 |
| Depth of Cut Maximum (APMX) | 5 mm | Series/List # | MS60..M-L50 |
| Inscribed Circle Diameter (IC) | 6.7 mm | Hole Diameter | 2.8 mm |
| Insert Thickness (S) | 3.74 mm | Cutting Edge Material | Carbide |
| Wiper Edge Length (BS) | 1 mm | Tool Type | Milling Indexable Insert |
| Coating | TiAlN | Coating Process | PVD |
| Grade | 1040 | Number of Cutting Edges | 6 |
| Shape | Triangle | Cutting Edge Effective Length (LE) | 5 mm |
| Insert Style | MS60 | Measurement Type | Metric |
Product Features
| Country of Origin | Sweden |
Shipping Info
Package Weight
0.042
