| Applicable Material | | Cast Iron | | Corner Chamfer Width (CHW) | 0.39 mm |
| Application | Shoulder Milling | Cutting Direction (HAND) | Neutral |
| Cutting Edge Length (L) | 17 mm | Chip Breaker Type | KLW |
| Depth of Cut Maximum (APMX) | 0.92 mm | Series/List # | 425N..E-KLW12 |
| Insert Width (W1) | 7.5 mm | Hole Diameter | 4.7 mm |
| Insert Thickness (S) | 10 mm | Cutting Edge Material | Carbide |
| Wiper Edge Length (BS) | 10.43 mm | Tool Type | Milling Indexable Insert |
| Coating | TiAlSiN | Coating Process | PVD |
| Grade | 1220 | Number of Cutting Edges | 8 |
| Shape | Rectangle | Cutting Edge Effective Length (LE) | 2.12 mm |
| Insert Style | 425N | Measurement Type | Metric |
| Insert Size | 1707 |
Product Features
| Country of Origin | Sweden |
Shipping Info
Package Weight
0.287
