F2334.B40.160.Z10.10 Copy Milling Cutter with round inserts
Indexable Face Mill; 140 mm Dia. × 40 mm Shank Dia. × 63 mm OAL × 10 mm Max Depth ; 10 Inserts ; Series F2334
| Cutting Diameter (DC/DCX) | 140 mm | Overall Length (OAL) | 63 mm |
| Cutting Diameter (DC) | 140 mm | Hub Diameter (DHUB) | 100 mm |
| Cutting Diameter Maximum (DCX) | 140 mm | Arbor Style | Arbor Hole |
| Cutting Item Count (CICT) | 10 | Cutting Direction (HAND) | Right Hand |
| Depth of Cut Maximum (APMX) | 10 mm | Series/List # | F2334 |
| Connection Diameter Machine Side (DCONMS) | 40 mm |
Product Features
| Country of Origin | Germany |
Shipping Info
Package Weight
9.51
