MTECM 16131E42 2.0ISO AC22
Thread Mill; M16 × 2 mm ; 0.63″ Shank Dia. × 4.134″ OAL ; Carbide ; TiAlN ; AC22
| Thread Size | M16 | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | |
| Thread Pitch (TP) | 2 mm | Cutting Edge Material | Carbide |
| Connection Diameter Machine Side (DCONMS) | 0.63″ | Cutting Position | Internal |
| Cutting Diameter (DC) | 0.516″ | Measurement Type | Inch |
| Overall Length (OAL) | 4.134″ | Grade | AC22 |
| Flute Count (NOF) | 5 | Depth of Cut Maximum (APMX) | 1.689″ |
| Shank Type | Round | Cutting Direction (HAND) | Right Hand |
| Coating | TiAlN | Body Material | Carbide |
| Application | | Internal Thread Milling | | Thread Form Type (THFT) | M60 |
Product Features
| Family Description | Solid Carbide Internal Threading Endmill Step Release, Lead x3 With Coolant Holes, Used for ISO Thread Profile | Country of Origin | Israel |
