MRW 125R1610T RAD-8 Series, Radius Face Mill
Indexable Face Mill; 125 mm Dia. × 38.1 mm Shank Dia. × 63 mm OAL × 8 mm LOC ; 10 Inserts ; Series MRW
| Cutting Diameter (DC/DCX) | 125 mm | Master Insert Identification (MIID) | ROMU1605M0ER-GM | ROMU1605M0ER-SM | ROMU1605M0ER-GH |
| Cutting Diameter (DC) | 125 mm | Coolant Supply Property (CSP) | Coolant Thru |
| Cutting Diameter Maximum (DCX) | 125 mm | Body Material | Steel |
| Cutting Item Count (CICT) | 10 | Cutting Direction (HAND) | Right Hand |
| Depth of Cut Maximum (APMX) | 8 mm | Application | Contouring | Facing | Plunging | Profiling | Shouldering |
| Connection Diameter Machine Side (DCONMS) | 38.1 mm | Measurement Type | Metric |
| Overall Length (OAL) | 63 mm | Series/List # | MRW |
| Hub Diameter (DHUB) | 89 mm |
Product Features
| Country of Origin | Japan |
Shipping Info
Package Weight
6.753
