MEAS 2000R134T Inch Bore Diameter, 90 Degree Face Mill
Indexable Face Mill; 2″ Dia. × 3/4″ Shank Dia. × 1.9685″ OAL × 0.4724″ LOC ; 4 Inserts ; 90 Degrees ; Series MEAS
| Cutting Diameter (DC/DCX) | 2″ | Ramping Angle Maximum (RMPX) | 6 Degrees |
| Cutting Diameter (DC) | 2″ | Coolant Supply Property (CSP) | Coolant Thru |
| Cutting Diameter Maximum (DCX) | 2″ | Body Material | Steel |
| Cutting Item Count (CICT) | 4 | Cutting Direction (HAND) | Right Hand |
| Depth of Cut Maximum (APMX) | 0.4724″ | Application | Contouring | Facing | Helical Milling | Plunging | Pocketing | Ramping | Shouldering | Slotting |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Measurement Type | Inch |
| Overall Length (OAL) | 1.9685″ | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Hub Diameter (DHUB) | 1-3/4″ | Series/List # | MEAS |
| Master Insert Identification (MIID) | KCGTFR-AL |
Product Features
| Country of Origin | China |
Shipping Info
Package Weight
1.372
