MRX 4000R167T RAD-6 Series, Radius Face Mill
Indexable Face Mill; 4″ Dia. × 1-1/2″ Shank Dia. × 1.9685″ OAL × 0.315″ LOC ; 7 Inserts ; Series MRX
| Cutting Diameter (DC/DCX) | 4″ | Master Insert Identification (MIID) | RPMT1605M0ER-GM | RPGT1605M0ER-GM | RPGT1605M0ER-SM | RPMT1605M0EN-GH | RPMW1605M0TN |
| Cutting Diameter (DC) | 4″ | Ramping Angle Maximum (RMPX) | 2 Degrees |
| Cutting Diameter Maximum (DCX) | 4″ | Coolant Supply Property (CSP) | Coolant Thru |
| Cutting Item Count (CICT) | 7 | Body Material | Steel |
| Depth of Cut Maximum (APMX) | 0.315″ | Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 1-1/2″ | Application | Facing | Pocketing | Profiling | Ramping | Shouldering | Slotting |
| Overall Length (OAL) | 1.9685″ | Measurement Type | Inch |
| Hub Diameter (DHUB) | 3.5402″ | Series/List # | MRX |
Product Features
| Country of Origin | Japan |
Shipping Info
Package Weight
4.114
