MFPN 458000R14T Inch Bore Diameter, 45 Degree Face Mill
Indexable Face Mill; 8.315″ Dia. × 2-1/2″ Shank Dia. × 2.4803″ OAL × 0.2362″ LOC ; 14 Inserts ; 45 Degrees ; Series MFPN
| Cutting Diameter (DC/DCX) | 8.315″ | Master Insert Identification (MIID) | PNMU1205ANER | PNEU1205ANER |
| Cutting Diameter (DC) | 8.315″ | Coolant Supply Property (CSP) | External |
| Cutting Diameter Maximum (DCX) | 8.315″ | Body Material | Steel |
| Cutting Item Count (CICT) | 14 | Cutting Direction (HAND) | Right Hand |
| Depth of Cut Maximum (APMX) | 0.2362″ | Application | Chamfering | Facing |
| Connection Diameter Machine Side (DCONMS) | 2-1/2″ | Measurement Type | Inch |
| Overall Length (OAL) | 2.4803″ | Tool Cutting Edge Angle (KAPR) | 45 Degrees |
| Hub Diameter (DHUB) | 5.5906″ | Series/List # | MFPN |
Product Features
| Country of Origin | Japan |
Shipping Info
Package Weight
15.600
