MSR 080R4M Metric Bore Diameter, 90 Degree Face Mill
Indexable Face Mill; 80 mm Dia. × 27 mm Shank Dia. × 115 mm OAL × 90 mm LOC ; 16 Inserts ; 90 Degrees ; Series MSR
| Cutting Diameter (DC/DCX) | 80 mm | Master Insert Identification (MIID) | APMT2506 |
| Cutting Diameter (DC) | 80 mm | Coolant Supply Property (CSP) | External |
| Cutting Diameter Maximum (DCX) | 80 mm | Body Material | Steel |
| Cutting Item Count (CICT) | 16 | Cutting Direction (HAND) | Right Hand |
| Depth of Cut Maximum (APMX) | 90 mm | Application | Facing | Heavy Milling | Shouldering | Slotting |
| Connection Diameter Machine Side (DCONMS) | 27 mm | Measurement Type | Metric |
| Overall Length (OAL) | 115 mm | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Hub Diameter (DHUB) | 55 mm | Series/List # | MSR |
Product Features
| Country of Origin | Japan |
Shipping Info
Package Weight
5.520
