MFPN 45080R8T 80.00MM
Indexable Face Mill; 93 mm Dia. × 25.4 mm Shank Dia. × 50 mm OAL × 6 mm LOC ; 8 Inserts ; 45 Degrees ; Series MFPN
| Cutting Diameter (DC/DCX) | 93 mm | Coolant Supply Property (CSP) | External |
| Cutting Diameter (DC) | 80 mm | Body Material | Steel |
| Cutting Diameter Maximum (DCX) | 93 mm | Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 8 | Application | Facing | Chamfering |
| Depth of Cut Maximum (APMX) | 6 mm | Measurement Type | Metric |
| Connection Diameter Machine Side (DCONMS) | 25.4 mm | Tool Cutting Edge Angle (KAPR) | 45 Degrees |
| Overall Length (OAL) | 50 mm | Tool Type | Face Mill |
| Hub Diameter (DHUB) | 60 mm | Series/List # | MFPN |
| Master Insert Identification (MIID) | PNMU1205… | PNEU1205… |
Product Features
| Family Description | Alternate Manufacture # MFPN45080R8T | Country of Origin | Japan |
Shipping Info
Package Weight
3.0161
