MEC 160R1712TM 160.00MM
Indexable Face Mill; 160 mm Dia. × 40 mm Shank Dia. × 63 mm OAL × 15.7 mm LOC ; 12 Inserts ; 90 Degrees ; Series MEC
| Cutting Diameter (DC/DCX) | 160 mm | Body Material | Steel |
| Cutting Diameter (DC) | 160 mm | Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 12 | Application | Facing | Shouldering | Slotting |
| Depth of Cut Maximum (APMX) | 15.7 mm | Measurement Type | Metric |
| Connection Diameter Machine Side (DCONMS) | 40 mm | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Overall Length (OAL) | 63 mm | Tool Type | Face Mill |
| Master Insert Identification (MIID) | BDMT1704..ER-JT | BDMT1704..ER-JS | BDGT1704..FR-JA | BDMT1704..FR | Series/List # | MEC |
| Coolant Supply Property (CSP) | External |
Product Features
| Family Description | Alternate Manufacture # MEC160R1712TM | Country of Origin | Japan |
Shipping Info
Package Weight
11.9601
