MFK 5000R1112T MFK 5.0000
Indexable Face Mill; 5.34″ Dia. × 1-1/2″ Shank Dia. × 2.4803″ OAL × 0.2362″ LOC ; 12 Inserts ; 70 Degrees ; Series MFK
| Cutting Diameter (DC/DCX) | 5.34″ | Coolant Supply Property (CSP) | External |
| Cutting Diameter (DC) | 5″ | Body Material | Steel |
| Cutting Diameter Maximum (DCX) | 5.34″ | Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 12 | Application | Facing | Cast Iron Milling |
| Depth of Cut Maximum (APMX) | 0.2362″ | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 1-1/2″ | Tool Cutting Edge Angle (KAPR) | 70 Degrees |
| Overall Length (OAL) | 2.4803″ | Tool Type | Face Mill |
| Hub Diameter (DHUB) | 3-3/4″ | Series/List # | MFK |
| Master Insert Identification (MIID) | PNMG11… | PNEG11… | PNEA11… |
Product Features
| Family Description | Alternate Manufacture # MFK5000R1112T | Country of Origin | Japan |
Shipping Info
Package Weight
8.7300
