MFK 3000R118T MFK 3.0000
Indexable Face Mill; 3.34″ Dia. × 1″ Shank Dia. × 2.4803″ OAL × 0.2362″ LOC ; 8 Inserts ; 70 Degrees ; Series MFK
| Cutting Diameter (DC/DCX) | 3.34″ | Coolant Supply Property (CSP) | External |
| Cutting Diameter (DC) | 3″ | Body Material | Steel |
| Cutting Diameter Maximum (DCX) | 3.34″ | Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 8 | Application | Facing | Cast Iron Milling |
| Depth of Cut Maximum (APMX) | 0.2362″ | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 1″ | Tool Cutting Edge Angle (KAPR) | 70 Degrees |
| Overall Length (OAL) | 2.4803″ | Tool Type | Face Mill |
| Hub Diameter (DHUB) | 2-3/4″ | Series/List # | MFK |
| Master Insert Identification (MIID) | PNMG11… | PNEG11… | PNEA11… |
Product Features
| Family Description | Alternate Manufacture # MFK3000R118T | Country of Origin | Japan |
Shipping Info
Package Weight
4.7070
