MSR 063R2 MSR 63.00MM
Indexable Face Mill; 50 mm Dia. × 25.4 mm Shank Dia. × 85 mm OAL × 45 mm LOC ; 8 Inserts ; 90 Degrees ; Series MSR
| Cutting Diameter (DC/DCX) | 50 mm | Coolant Supply Property (CSP) | External |
| Cutting Diameter (DC) | 63 mm | Body Material | Steel |
| Cutting Diameter Maximum (DCX) | 50 mm | Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 8 | Application | Facing | Shouldering | Slotting | Heavy Milling |
| Depth of Cut Maximum (APMX) | 45 mm | Measurement Type | Metric |
| Connection Diameter Machine Side (DCONMS) | 25.4 mm | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Overall Length (OAL) | 85 mm | Tool Type | Face Mill |
| Master Insert Identification (MIID) | APMT2506… | Series/List # | MSR |
Product Features
| Family Description | Alternate Manufacture # MSR063R2 | Country of Origin | Japan |
Shipping Info
Package Weight
2.2265
