MECX 2000R0712T 2.0000
Indexable Face Mill; 1.575″ Dia. × 3/4″ Shank Dia. × 1.5748″ OAL × 0.2362″ LOC ; 12 Inserts ; 90 Degrees ; Series MECX
| Cutting Diameter (DC/DCX) | 1.575″ | Coolant Supply Property (CSP) | Coolant Thru |
| Cutting Diameter (DC) | 2″ | Body Material | Steel |
| Cutting Diameter Maximum (DCX) | 1.575″ | Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 12 | Application | Facing | Shouldering | Slotting |
| Depth of Cut Maximum (APMX) | 0.2362″ | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Overall Length (OAL) | 1.5748″ | Tool Type | Face Mill |
| Master Insert Identification (MIID) | BDMT0703..ER-JT | BDMT0703..ER-JS | Series/List # | MECX |
Product Features
| Family Description | Alternate Manufacture # MECX2000R0712T | Country of Origin | Japan |
Shipping Info
Package Weight
1.1204
