M-SIX 160.00MM FACE MILL
Indexable Face Mill; 102 mm Dia. × 50.8 mm Shank Dia. × 63 mm OAL × 8 mm LOC ; 8 Inserts ; 90 Degrees ; Series M-SIX
| Cutting Diameter (DC/DCX) | 102 mm | Coolant Supply Property (CSP) | External |
| Cutting Diameter (DC) | 160 mm | Body Material | Steel |
| Cutting Diameter Maximum (DCX) | 102 mm | Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 8 | Application | Facing | Shouldering | Slotting | Plunging |
| Depth of Cut Maximum (APMX) | 8 mm | Measurement Type | Metric |
| Connection Diameter Machine Side (DCONMS) | 50.8 mm | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Overall Length (OAL) | 63 mm | Tool Type | Face Mill |
| Master Insert Identification (MIID) | PNMU1205… | PNEU1205… | Series/List # | M-SIX |
Product Features
| Family Description | Alternate Manufacture # MFWN90160R8T | Country of Origin | Japan |
Shipping Info
Package Weight
9.1772
