3/8″ VAR 5F 1.125″LOC
SQ End Mill; 3/8″ Dia. × 1-1/8″ LOC × 3/8″ Shank Dia. × 3″ OAL ; 5 FL ; Carbide ; AlCr ; Series 3922L
| Cutting Diameter (DC) | 3/8″ | End Shape | Square |
| Connection Diameter Machine Side (DCONMS) | 3/8″ | Applicable Material | | Universal Materials | |
| Depth of Cut Maximum (APMX) | 1-1/8″ | Application | | Finishing | |
| Overall Length (OAL) | 3″ | Tool Type | End Mill |
| Cutting Edge Material | Carbide | Decimal Equivalent | 0.375″ |
| Coating | AlCr | Series/List # | 3922L |
| Flute Count (NOF) | 5 | Trade Name | Top-Cut VAR |
| Shank Type | Round |
Product Features
| Remarks | • TOP-Cut VAR carbide end mill with 5 flute design for roughing and finishing in almost all materials • Variable pitch helix angle enable low-vibration machining and universal use in almost all materials and milling processes • Suitable for trochoidal milling tool paths • ALCR coating for additional heat and wear resistance | Country of Origin | USA |
Shipping Info
Package Weight
0.25
