WL25-VC0704NTM-3 WBH20C
Turning Insert; 35 Rhombic ; 25 mm Length × 12.7 mm IC × 0.4 mm Corner Radius ; WBH20C ; CBN ; CBN
Additional Tariff Surcharge of 8 %
| Applicable Material | | Hard Materials | | Min D.O.C. | 0.1 mm |
| Corner Radius (RE) | 0.4 mm | Depth of Cut Maximum (APMX) | 0.5 mm |
| Insert Size | 250404 | Clearance Angle Major (AN) | 7 Degrees |
| Cutting Edge Length (L) | 25 mm | Number of Cutting Edges | 3 |
| Insert Thickness (S) | 4.76 mm | Cutting Direction (HAND) | Neutral |
| Inscribed Circle Diameter (IC) | 12.7 mm | Chip Breaker Type | TM |
| Cutting Edge Material | CBN | Measurement Type | Metric |
| Coating | CBN | Shape | 35° Rhombic |
| Grade | WBH20C | Cutting Depth Maximum (CDX) | 0.5 mm |
| Fixing Hole Diameter (D1) | 5.5 mm | Cutting Edge Effective Length (LE) | 25 mm |
| Tool Type | Turning Insert | Model No | WL25-VC0704NTM-3 WBH20C |
Product Features
| Country of Origin | Germany |
Shipping Info
Package Weight
0.029
