CNMX 19 11 40 PF 4415
Turning Insert; 80 Diamond × 19.05 mm IC × 4 mm Corner Radius ; 4415 ; | Al2O3 | TiN | TiCN |
Additional Tariff Surcharge of 8 %
| Applicable Material | | Steel | Cast Iron | | Fixing Hole Diameter (D1) | 7.8 mm |
| Insert Style | CNMX | Clearance Angle Major (AN) | 0 Degrees |
| Corner Radius (RE) | 4 mm | Number of Cutting Edges | 4 |
| Insert Size | 1911 | Cutting Direction (HAND) | Neutral |
| Insert Thickness (S) | 11 mm | Measurement Type | Metric |
| Inscribed Circle Diameter (IC) | 19.05 mm | Shape | 80° Diamond |
| Coating | | Al2O3 | TiN | TiCN | | Cutting Edge Effective Length (LE) | 15.34 mm |
| Grade | 4415 |
Product Features
| Country of Origin | Sweden |
