3/4X3/4X1 1/2X6 3FL RH CB
Square End Mill; 3/4″ Dia. × 1-1/2″ LOC × 3/4″ Shank Dia. × 6″ OAL ; 3 FL ; Carbide ; Ta-C ; Series 337
| Cutting Diameter (DC) | 3/4″ | Grade | A5005 Exxtral Carbon (DLC) |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Peripheral Effective Cutting Edge Count (ZEFP) | 3 |
| Depth of Cut Maximum (APMX) | 1-1/2″ | Tool Type | Solid Carbide Endmill |
| Overall Length (OAL) | 6″ | Maximum Feed per Tooth (fz(max)) | 0.01 ″/tooth |
| Cutting Edge Material | Carbide | Minimum Feed per Tooth (fz(min)) | 0.003 ″/tooth |
| Coating | Ta-C | Length Group | Extra Long |
| Flute Count (NOF) | 3 | Shank Standard | h6 |
| Flute Helix Angle (FHA) | 37 Degrees | Body Material | Carbide |
| Shank Type | Round | Decimal Equivalent | 0.75″ |
| End Shape | Square | Measurement Type | Inch |
| Usable Length (LU) | 1-1/2″ | Series/List # | 337 |
| Application | Finishing | HEM | Roughing | Semi Finishing | Slotting | Shank Size (SS) | 3/4″ |
Product Features
| Family Description | 337 SERIES 3 FLUTE FOR ALUMINUM & NON FERROUS MATERIAL (37° HELIX) | Country of Origin | USA |
Shipping Info
Package Weight
1.728
