GDGS 4020N040NB KBN570 Grade CBN, Indexable Grooving Insert
Grooving Insert; 4 mm CW × 25.5 mm Max Depth × 4.3 mm Thickness ; CBN ; KBN570 ; Series KGD
| Cutting Width (CW) | 4 mm | Number of Cutting Edges | 1 |
| Corner Radius (RE) | 0.4 mm | Chip Breaker Type | NB |
| Cutting Depth Maximum (CDX) | 25.5 mm | Insert Style | GDGS |
| Insert Thickness (S) | 4.3 mm | Number of Teeth | 1 |
| Insert Length (INSL) | 20 mm | Mounting Style | Clamp |
| Grade | KBN570 | Series/List # | KGD |
| Cutting Edge Material | CBN | Coating Process | Uncoated |
| Application | | Ext. Grooving | | Measurement Type | Metric |
| Applicable Material | | Steel | | Cutting Edge Length (L) | 2.9 mm |
| Cutting Direction (HAND) | Neutral |
Product Features
| Country of Origin | Japan |
Shipping Info
Package Weight
.042
Related Documentation
