M4574-016-T14-03-03
Indexable End Mill; 16 mm Dia. × 3.5 mm LOC × 14.5 mm Shank Dia. × 43 mm OAL ; Threaded Shank ; 45 Degrees ; Series M4574
Additional Tariff Surcharge of 8 %
| Cutting Diameter (DC/DCX) | 16 mm | Connection Diameter Machine Side (DCONMS) | 14.5 mm |
| Cutting Diameter (DC) | 16 mm | Head Length (LH) | 25 mm |
| Cutting Item Count (CICT) | 3 | Coolant Supply Property (CSP) | Coolant Thru |
| Depth of Cut Maximum (APMX) | 3.5 mm | Tool Cutting Edge Angle (KAPR) | 45 Degrees |
| Overall Length (OAL) | 43 mm | Cutting Direction (HAND) | Right Hand |
| Shank Type | Threaded | Series/List # | M4574 |
Product Features
| Country of Origin | China |
Shipping Info
Additional Fees and Notes
0
Package Weight
0.617
