WL25-RC0525N-MU6 WSM20S
Turning Insert; Round ; 25 mm Length × 12.7 mm IC × 2.5 mm Corner Radius ; WSM20S ; Carbide ; | Al2O3 | TiAlN |
Additional Tariff Surcharge of 8 %
| Applicable Material | | Steel | Stainless Steel | Super-Alloys / Titanium | | Depth of Cut Maximum (APMX) | 2.5 mm |
| Corner Radius (RE) | 2.5 mm | Clearance Angle Major (AN) | 7 Degrees |
| Insert Size | 250425 | Number of Cutting Edges | 3 |
| Cutting Edge Length (L) | 25 mm | Cutting Direction (HAND) | Neutral |
| Insert Thickness (S) | 4.76 mm | Chip Breaker Type | MU6 |
| Inscribed Circle Diameter (IC) | 12.7 mm | Measurement Type | Metric |
| Cutting Edge Material | Carbide | Shape | Round |
| Coating | | Al2O3 | TiAlN | | Body Material | Solid Carbide |
| Grade | WSM20S | Cutting Depth Maximum (CDX) | 2.5 mm |
| Fixing Hole Diameter (D1) | 5.5 mm | Cutting Edge Effective Length (LE) | 25 mm |
| Tool Type | Turning Insert | Model No | WL25-RC0525N-MU6 WSM20S |
| Min D.O.C. | 0.5 mm |
Product Features
| Country of Origin | Germany |
Shipping Info
Package Weight
0.033
