CDCD 51 C22
Turning Insert; 60 Triangle × 3/8″ IC × 0.015″ Corner Radius ; C22 ; Carbide ; Uncoated
| Applicable Material | Steel | Stainless Steel | Super-Alloys / Titanium | Fixing Hole Diameter (D1) | 0.1772″ |
| Application | Back Boring | Boring | Copying | External Turning | Internal Facing | Tool Type | Boring Insert |
| Insert Style | CDCD | Clearance Angle Major (AN) | 11 Degrees |
| Corner Radius (RE) | 0.015″ | Number of Cutting Edges | 3 |
| Insert Size | 321 | Cutting Direction (HAND) | Right Hand |
| Insert Thickness (S) | 0.04″ | Quantity | 10 |
| Inscribed Circle Diameter (IC) | 3/8″ | Measurement Type | Inch |
| Insert Included Angle (EPSR) | 60 Degrees | Shape | 60° Triangle |
| Cutting Edge Material | Carbide | Series/List # | ISOI |
| Coating | Uncoated | Insert Width (W1) | 0.156″ |
| Grade | C22 | Model No | 8866423 |
Product Features
| Country of Origin | USA |
Shipping Info
Package Weight
0.04
