VNGA 3302 ME KBN10M, 0.0039″ Corner Radius, 3/16″ Thick, 3/8″ Inscribed Circle, MEGACOAT, Diamond, Turning Indexable Insert
Turning Insert; Diamond x 3/8″ IC × 0.0039″ Corner Radius ; KBN10M ; CBN ; MEGACOAT
| Applicable Material | | Hard Materials | | Coating | MEGACOAT |
| Application | External Turning | Copying | Facing | Undercutting | Grade | KBN10M |
| Insert Style | VNGA | Fixing Hole Diameter (D1) | 0.15″ |
| Corner Radius (RE) | 0.0039″ | Clearance Angle Major (AN) | 0 Degrees |
| Insert Size | 3302 | Number of Cutting Edges | 2 |
| Insert Thickness (S) | 3/16″ | Cutting Direction (HAND) | Neutral |
| Inscribed Circle Diameter (IC) | 3/8″ | Chip Breaker Type | ME |
| Cutting Edge Material | CBN | Shape | Diamond |
Product Features
| Family Description | Alternate Manufacture # VNGA3302S00525MEKBN10M | Country of Origin | Japan |
Shipping Info
Package Weight
.0432
