SPG 433 flat_top MBS140, 3/64″ Corner Radius, 3/16″ Thick, 1/2″ Inscribed Circle, Turning Indexable Insert
Turning Insert; Square ; 0.508″ Length × 12.7 mm IC × 1.2 mm Corner Radius ; MBS140 ; CBN
| Applicable Material | | Cast Iron | | Cutting Edge Material | CBN |
| Insert Style | SPG | Grade | MBS140 |
| Corner Radius (RE) | 1.2 mm | Cutting Direction (HAND) | Neutral |
| Insert Size | 433 | Chip Breaker Type | flat_top |
| Cutting Edge Length (L) | 0.508″ | Measurement Type | Metric |
| Insert Thickness (S) | 4.76 mm | Shape | Square |
| Inscribed Circle Diameter (IC) | 12.7 mm | Series/List # | MBS140 |
| Insert Included Angle (EPSR) | 90 Degrees |
Product Features
| Country of Origin | Japan |
Shipping Info
Package Weight
0.1
