DNG 23 flat_top MBS140, 3/64″ Corner Radius, 1/8″ Thick, 3/8″ Inscribed Circle, Turning Indexable Insert
Turning Insert; 55 Rhombic × 9.525 mm IC × 1.2 mm Corner Radius ; MBS140 ; CBN
| Applicable Material | | Cast Iron | | Grade | MBS140 |
| Insert Style | DNG | Cutting Direction (HAND) | Neutral |
| Corner Radius (RE) | 1.2 mm | Chip Breaker Type | flat_top |
| Insert Size | 23 | Measurement Type | Metric |
| Insert Thickness (S) | 3.18 mm | Shape | 55° Rhombic |
| Inscribed Circle Diameter (IC) | 9.525 mm | Series/List # | MBS140 |
| Insert Included Angle (EPSR) | 55 Degrees | Cutting Edge Effective Length (LE) | 9.912 mm |
| Cutting Edge Material | CBN |
Product Features
| Country of Origin | Japan |
