7960258 WALTER INDEXABLE
Turning Insert; 35 Rhombic ; 25 mm Length × 12.7 mm IC × 0.4 mm Corner Radius ; WPP20S ; Carbide ; | Al2O3 | TiN | TiCN |
| Applicable Material | | Steel | | Depth of Cut Maximum (APMX) | 2.5 mm |
| Corner Radius (RE) | 0.4 mm | Clearance Angle Major (AN) | 7 Degrees |
| Cutting Edge Length (L) | 25 mm | Number of Cutting Edges | 3 |
| Insert Thickness (S) | 4.76 mm | Cutting Direction (HAND) | Left Hand |
| Inscribed Circle Diameter (IC) | 12.7 mm | Chip Breaker Type | MP4 |
| Cutting Edge Material | Carbide | Measurement Type | Metric |
| Coating | | Al2O3 | TiN | TiCN | | Shape | 35° Rhombic |
| Grade | WPP20S | Series/List # | WL-VCL-MP4 |
| Fixing Hole Diameter (D1) | 5.5 mm | Cutting Depth Maximum (CDX) | 2.5 mm |
| Tool Type | Turning Insert | Cutting Edge Effective Length (LE) | 25 mm |
| Min D.O.C. | 0.4 mm | Model No | WL25-VC0704L-MP4 WPP20S |
Product Features
| Country of Origin | Germany |
Shipping Info
Package Weight
0.999
