MDW02500GS2 1/4″ Dia. × 9/32″ Shank × 1.2205″ Flute Length × 2.874″ OAL, DEX, External Coolant, Cylindrical Solid Carbide Drill
SC Drill; 1/4″ Dia. × 9/32″ Shank Dia. × 2.874″ OAL × 1.2205″ LCF
| Drill Bit Size / Cutting Diameter (DC) | 1/4″ | Shape | Solid Carbide |
| Drill Bit Size / Cutting Diameter (DC) - Inch | 1/4″ | Cutting Edge Material | Carbide |
| Decimal Equivalent | 0.25″ | Tool Type | Solid Carbide Drills |
| Length Group | 2xD | Point Shape | 135 Degrees |
| Coating | DEX | Measurement Type | Inch |
| Applicable Material | | Steel | Cast Iron | | Usable Length (LU) | 0.8455″ |
| Connection Diameter Machine Side (DCONMS) | 9/32″ | Length Chip Flute (LCF) | 1.2205″ |
| Coolant Supply Property (CSP) | External | Overall Length (OAL) | 2.874″ |
| Point Angle (SIG) | 135 Degrees | Flute Count (NOF) | 2 |
| Shank Type | Round | Cutting Direction (HAND) | Right Hand |
Product Features
| Country of Origin | USA |
Shipping Info
Package Weight
0.08
