CAPTO C5 X ER16-100mm Collet Chuck
Collet Chuck ; C5 Shank Size ; ER16 Connection Size ; 28 mm Body Dia. ; Capto Shank
| Shank Size (SS) | C5 | Protruding Length (LPR) | 100 mm |
| Connection Size (CSI) | ER16 | Shank Type | Capto |
| Body Diameter (BD) | 28 mm | Coolant Supply Property (CSP) | Coolant Thru |
Product Features
| Remarks | •For turn/mill machines that accept "C" style toolholders•Balanced to 25,000 RPM at G2.5 tolerance•Each holder is individually lab tested and certified for quality and accuracy and comes with it's own report•T.I.R. is 0.0001″ or better•PowerCOAT nut is included for 75% greater clamping power than a standard nut | Country of Origin | Taiwan |
Shipping Info
Package Weight
1
