ULTRA-DEX 920 C04H SCLDR1.5 1/4″ Carbide Boring Bar Positive 80DEG Diamond KAPR 95DEG 8:1 Ratio Right Hand No Coolant

Int. Turning Tool ; 4″ OAL ; 1/4″ Shank Dia. ; 4″ LF ; .312″ Min Bore Dia.

Item # 0509303

Brand: ARCH Cutting Tools

MFG #: ‎920-000-010

Alternate MFG #: C04HSCLDR15

Legacy Part #: FG550007

UPC #: ‎920-000-010

Trade Name: ULTRA-DEX

Connection Diameter Machine Side (DCONMS)

1/4″

Master Insert Identification (MIID)

CDGW 1.510

Functional Length (LF)

4″

Minimum Bore Diameter (DMIN)

.312″

Overall Length (OAL)

4″

Cutting Direction (HAND)

Right Hand

Reduced Body Diameter Length (LDRED)

0.275″

Tool Type

Indexable Boring Bar

Functional Width (WF)

.172″

Style

SCLCR

Product Features

Remarks

•80° Diamond5° Lead AngleNo Coolant •The highest standards for quality •The braze on our bars is guaranteed not to fail.

Country of Origin

USA

Package Length

4.30000

Package Width

2.12500

Package Height

.38000

Package Weight

0.12
