5/16″ Min-3/4″ Max Bore-3/8″ SH-2″ OAL - Carbide Tip Boring Bar
Boring Bar; 3/8″ Shank Dia. × 5/16″ Min Bore Dia. × 2″ LF ; Carbide
| Connection Diameter Machine Side (DCONMS) | 3/8″ | Grade | C2 |
| Minimum Bore Diameter (DMIN) | 5/16″ | Cutting Edge Material | Carbide |
| Functional Length (LF) | 2″ | Tool Type | Boring Bars |
| Head Length (LH) | 3/4″ |
Product Features
| Remarks | •Carbide Tipped Boring Bars •All minimum hole sizes come in three lengths:Short - For counter boring and short hole workMedium - For general boringLong - For those extra depth holes where generally the tool room has to make up special tooling •We offer two types of carbide tips:C-2 General Purpose: Cast Iron & Non-ferrousC-6 General Purpose: Steel and Steel Alloys •These tools are a quality tool designed to be used and sold as a boring tool bit. | Country of Origin | USA |
Shipping Info
Package Weight
.060
