16 ER150ISOTQ PR1215 ALT MFG #16ER150ISOTQPR1215
Laydown Threading Insert ; 1.5 mm TP ; 9.53 mm IC ; Metric (M) ; Carbide ; PR1215 ; MEGACOAT ; Series PR12-Series
| Thread Standard | Metric (M) | Insert Style | 16 |
| Inscribed Circle Diameter (IC) | 9.53 mm | Mounting Style | Clamp |
| Thread Pitch (TP) | 1.5 mm | Cutting Direction (HAND) | Right Hand |
| Corner Radius (RE) | 0.19 mm | Chip Breaker Type | TQ |
| Insert Thickness (S) | 3.68 mm | Angle | 60 Degrees |
| Grade | PR1215 | Cutting Item Count (CICT) | 3 |
| Coating | MEGACOAT | Series/List # | PR12-Series |
| Cutting Edge Material | Carbide | Measurement Type | Metric |
| Cutting Position | External | Hole Diameter | 4 mm |
| Application | External Threading | Insert Seat Size Code (SSC) | 150 |
| Applicable Material | | Steel | Stainless Steel | |
Product Features
| Family Description | Alternate Manufacture # 16ER150ISOTQPR1215 | Country of Origin | Japan |
Shipping Info
Package Weight
.0829
